Custom Tungsten Carbide Parts

  • Customized Non-standard Cemented Tungsten Carbide Wear Parts
  • Customized Non-standard Cemented Tungsten Carbide Wear Parts
  • Customized Non-standard Cemented Tungsten Carbide Wear Parts
  • Customized Non-standard Cemented Tungsten Carbide Wear Parts
Customized Non-standard Cemented Tungsten Carbide Wear Parts Customized Non-standard Cemented Tungsten Carbide Wear Parts Customized Non-standard Cemented Tungsten Carbide Wear Parts Customized Non-standard Cemented Tungsten Carbide Wear Parts

Customized Non-standard Cemented Tungsten Carbide Wear Parts

  • Place of Origin: Zhuzhou, Hunan
  • Brand Name: Zhenfang
  • Certification: ISO9001:2015
  • Grade: K10 K20 K30 YL10.2 YN8 YN9
  • Minimum Order Quantity:5KGS
  • Price:Negotiable
  • Delivery Time:3-10days
  • Payment Terms:L/C, D/A, D/P, T/T, Western Union
  • Supply Ability:15tons/month

Customized Non-standard Cemented Tungsten Carbide Wear Parts

Tungsten carbide is widely used in industry because of its extraordinary properties. Because of its wear resistance and hardness, tungsten carbide is ideally suited for wear parts, other machine parts and dies which are subject to severe service conditions, such as high temperatures, corrosion and abrasion.. In recent years, tungsten carbide has emerged as a superior alternative to steel in many industrial applications.


1.Product name: Cemented carbide customized wear parts

2.Common material: YG6,YG8,YG10,YG11,YG13,YG15,YG20 etc.

3.Main products: Customized moulds & dies, rod, plate, strips, cutting tools, TC ring and roller, mining buttons, carbide tips.
4.Dimension: Customized following your drawing

5.Certification: ISO9001


Grade information  for carbide wear parts

Grade
Density (g/cm3)
Hardness (HRA)
T.R.S (MPa)
Application recommended
YG6
14.95
90.5
1900
For coring crowns,electric coal drill bits,coal cutting picks,oil cone bits and scraping knife bits,used in geological prospecting,coal mining and oil well boring.
YG8
14.8
89.8
2800
Used as a core drill, electric coal drill, coal cutter tooth, oil roller bit and scraper button bit.
YG8C
14.8
89.8
2800
Mainly used for small and medium-sized drill bit tooth, and as a rotating exploration drill bush.
YG11C
14.4
86.5
2700
Most used in the drill bit and rock bit used for cutting high hardness materials ball tooth.
YG13C
14.2
86
2900
mainly used for rotary drill bit used for cutting high hardness materials in ball mill.
YG15C
14
85
3000
Used in oil cone bit and soft in the hard rock digging cutting tools.
YK05
14.9
90.5
2600
Mostly used as the buttons of small and mediumsized bits to cut soft and medium hard formations
YK15
14.6
88
2750
Suitable to strips,conical buttons for rotary percussion-resistant geological prospecting buttons,cut soft and medium hard
formations.

Various grades and Sintered Tungsten Carbide Wear Parts for metal forming and Wear resistant applications are available in the following range.



MECHANICAL SEAL RINGS
Tungsten Carbide Seal Rings are used as Mechanical Seal faces in pumps, Compressors and Agitators. These are used in Oil Refineries, Petrochemical plants, Fertilizer Plants, and Drugs/Pharmaceutical Industries.
Mechanical seal rings are developed to withstand high temperature, high pressure & highly corrosive chemical attack. We manufacture Rings in various shapes like Plain Ring, DA type, T-shape, L-shape and in shapes as per customers requirement.
Tungsten Carbide Rings are generally made with Cobalt as binder material. Nickel bonded Rings also can be supplied.

 PELLETS / NIBS

To serve the Metal Drawing Industry, we manufacture tungsten carbide Wire, Bar and Tube Drawing Pellets. A high hardness combined with good toughness is provided to withstand extremes of temperature and pressure. The wear resistance property of tungsten carbide wear part can lead to extended die life while achieving desired quality of material drawn such as surface finish and dimensional accuracy.
JUTE EYELETS
Tungsten Carbide wear parts used in spinning and weaving machinery particularly in jute industry are eyelets. These are to prevent vibration/ deflection of jute thread at high speed. Tungsten Carbide jute eyelets give long uninterrupted running of the machine.

Tungsten carbide jute eyelets are available in different sizes and shapes namely Half moon, Flyer leg Insert, N-K eye, P/spindle eye, N-K strip, Small carbide eye, Big carbide eye, Nozzle eye, etc.



Packing and Delivery

Packing Details : Normal Netural Packing.
Delivery Details : 5-15 days after receiving the advance payment.
