Molybdenum Products

Customize high purity molybdenum product for electrode molybdenum plate

Customize high purity molybdenum product for electrode molybdenum plate

Place of Origin： China
Brand Name： Zhenfang
Certification： ISO9001:2015
Grade： Mo 1
Minimum Order Quantity:100 pcs
Price:USD 15-20/pcs
Delivery Time:15-25 days
Payment Terms:T/T, western union,
Supply Ability:10000 kg/month

Customize high purity molybdenum product for electrode molybdenum plate

Pls feel free to contact us you have any requirments, any inquiry is welcomed!

Contact person:Ms Sharon Chen

Whatapp:+86 13823202651

WeChat;18173388506

Email address:sharon@chinahardalloy.com

Website:www.wmcarbide.com

Product Description

1. Molybdenum block is resistant to high temperature and owns favorable heat conductivity, toughness and low expansion coefficient. So it’s an ideal component in aerospace engineering and military field. molybdenum block
2. Covering small size of thermal neutron capture enables molybdenum block become structural material in nuclear reactor.
3. Pure molybdenum materials are often used in MOCVD or ion implantation.

4.We can make logo follow your requirements

molybdenum block

Advantage

Molybdenum plate has so many advantages, such as high density, high melting point, small volume, excellent hardness, superior wearing resistance, high ultimate tensile strength, high ductility, high temperature resistance, etc. Molybdenum alloys are widely used in many industrial sectors.
Molybdenum alloy plate can be easily used for car weighting .The product also is manufactured as the parts of military defense, extrusion die, various counterweights, such as yacht counterweights, vehicle counterweights, airplane counterweights, helicopter counterweights, boat counterweights, tank counterweights, etc.Usually, molybdenum alloy cylinder could be manufactured as the parts for military applications, extrusion die and various kinds of counterweights.

Specification:

Purity:>=99.95%

Density:>=10.2g/cm3

Thickness :>=0.1mm

Width: 20-600mm
Length: Less than 2000mm

Standard:ASTM,GB3876-83

Molybdenum block
Thickness(mm)	tolerances(mm)	width(mm)	tolerances(mm)	length(mm)	tolerances(mm)	flatness(%)
0.1mm	±0.01	600mm	±1mm	2000mm	±5mm	< 2%
0.2mm	±0.02	600mm	±1mm	2000mm	±5mm	< 2%
0.3mm	±0.02	600mm	±1mm	2000mm	±5mm	< 2%
0.4mm	±0.03	600mm	±1mm	2000mm	±5mm	< 2%
0.5mm	±0.03	600mm	±1mm	2000mm	±5mm	< 2%
0.8mm	±0.05	600mm	±1mm	2000mm	±5mm	< 2%
1mm	±0.06	600mm	±1mm	2000mm	±5mm	< 2%
1.5mm	±0.06	600mm	±1mm	2000mm	±5mm	< 2%
2mm	±0.06	600mm	±1mm	2000mm	±5mm	< 2%
3mm	±0.2	500	±1mm	500	±2mm	< 2%
4mm	±0.2	500	±1mm	500	±2mm	< 2%

Our testing for molybdenum block
Fe	Ni	C	Al	O	N
0.004	0.002	0.0028	0.0005	0.005	0.002
Si	Ca	Mg	Cd	Sb	Sn
0.0013	< 0.001	< 0.0005	< 0.001	< 0.0005	< 0.0005
P	Cu	Pb	Bi	Mo
< 0.001	< 0.0005	< 0.0005	< 0.0005	>99.95%

Molybdenum products	Molybdenum plate/sheet/foil (min 0.05mm); MoLa molybdenum tray molybdenum rod/bar/wire; molybdenum alloy MoLa box Molybdenum crucible,molybdenum boat/container,molybdenum tube. Molybdenum heating element for vacuum furnace and high temperature furnace. Molybdenum part made to required drawings.
Molybdenum alloy	TZM alloy,MoLa alloy. molybdenum block
Tungsten products	Tungsten plate/sheet/foil (min 0.05mm); molybdenum alloy MoLa boMoLa tray Tungsten rod/bar/wire; molybdenum block Tungsten crucible,tungsten boat/container,tungsten tube. Tungsten heating element for vacuum furnace and high temperature furnace. Tungsten part made to customer's drawings.
Tungsten alloy	WCu alloy,WLa,WNiFe and WNiCu heavy alloy. molybdenum block

Company Profile

Factory Sell Purity 99.95% Molybdenum block, plate with superior quality custom size(图1)

Zhuzhou Zhenfang Tungsten Molybdenum Co., Ltd. located in Zhuzhou City, Hunan Province-the world-renowned research and production base of nonferrous metal.
Our company has over 10 years' experience in manufacture ,design and sale of  carbide products. We have ourown two factories- Zhuzhou Mincheng and Zhuzhou Teliya. Our perfect quality control systerm guarantees our products quality.  Our main products include: tungsten carbide rods, carbide sheet, carbide wear parts,  carbide cutting tools, carbide moulds,non-standard and deep processing products,etc; pure tugnsten rod,tugnsten wire, molybdenum wire. We also accept all kinds of special designed carbide products.
Our company gathered professional staffs in design, producing and sale.
We treat "High quality","Best price",Sincere service" as the soul of our factory. We try our best to supply more reliable and economical products to our clients. We always seek Win-Win cooperation with our clients. Warmly welcome to contact and visit us at any time. It is our pleasure to help you.

FAQ

1. who are we?
We are based in Hunan, China, start from 2011,sell to Southeast Asia(18.00%),North America(11.00%),South America(10.00%),Western Europe(9.20%),Eastern Asia(8.00%),Eastern Europe(7.00%),Northern Europe(5.00%),South Asia(5.00%),Southern Europe(3.00%),Mid East(2.00%),Central America(1.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
tungsten carbide rod,tungsten carbide bar,tungsten carbide wear parts,tungsten carbide blanks,tungsten carbide cutting tools tips

4. why should you buy from us not from other suppliers?
We have over 10 years experience in tugnsten carbide manufacturing  and developing.  Perfect quality control systerm. High products quality and speedy delivery.  professional sales team. Customization is accepted.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,Express Delivery；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
