Molybdenum Products

  • Factory Sell Purity 99.95% Molybdenum block, plate  with superior quality custom size
  • Factory Sell Purity 99.95% Molybdenum block, plate  with superior quality custom size
  • Factory Sell Purity 99.95% Molybdenum block, plate  with superior quality custom size
Factory Sell Purity 99.95% Molybdenum block, plate  with superior quality custom size Factory Sell Purity 99.95% Molybdenum block, plate  with superior quality custom size Factory Sell Purity 99.95% Molybdenum block, plate  with superior quality custom size

Factory Sell Purity 99.95% Molybdenum block, plate with superior quality custom size

  • Place of Origin: China
  • Brand Name: Zhenfang
  • Certification: ISO9001:2015
  • Grade: Mo1
  • Minimum Order Quantity:10 pcs
  • Price:USD 55-75/kg
  • Delivery Time:5-10 days
  • Payment Terms:T/T, western union, LC etc
  • Supply Ability:10000kg/month

Factory Sell Purity 99.95% Molybdenum block, plate  with superior quality custom size

Pls feel free to contact us you have any requirments, any inquiry is welcomed!

Contact person:Ms Sharon Chen

Whatapp:+86 13823202651

WeChat;18173388506

Email address:sharon@chinahardalloy.com

Website:www.wmcarbide.com


Product Description

1. Molybdenum block is resistant to high temperature and owns favorable heat conductivity, toughness and low expansion coefficient. So it’s an ideal component in aerospace engineering and military field.  molybdenum block
2. Covering small size of thermal neutron capture enables molybdenum block become structural material in nuclear reactor.
3. Pure molybdenum materials are often used in MOCVD or ion implantation.

4.We can make logo follow your requirements

molybdenum block


Advantage

Molybdenum plate has so many advantages, such as high density, high melting point, small volume, excellent hardness, superior wearing resistance, high ultimate tensile strength, high ductility, high temperature resistance, etc. Molybdenum alloys are widely used in many industrial sectors.
Molybdenum alloy plate can be easily used for car weighting .The product also is manufactured as the parts of military defense, extrusion die, various counterweights, such as yacht counterweights, vehicle counterweights, airplane counterweights, helicopter counterweights, boat counterweights, tank counterweights, etc.Usually, molybdenum  alloy cylinder could be manufactured as the parts for military applications, extrusion die and various kinds of counterweights.


Specification:

Purity:>=99.95%

Density:>=10.2g/cm3

Thickness :>=0.1mm

Width: 20-600mm
Length: Less than 2000mm

Standard:ASTM,GB3876-83



Molybdenum block
Thickness(mm)tolerances(mm)width(mm)tolerances(mm)length(mm)tolerances(mm)flatness(%)
0.1mm±0.01600mm±1mm2000mm±5mm< 2%
0.2mm±0.02600mm±1mm2000mm±5mm< 2%
0.3mm±0.02600mm±1mm2000mm±5mm< 2%
0.4mm±0.03600mm±1mm2000mm±5mm< 2%
0.5mm±0.03600mm±1mm2000mm±5mm< 2%
0.8mm±0.05600mm±1mm2000mm±5mm< 2%
1mm±0.06600mm±1mm2000mm±5mm< 2%
1.5mm±0.06600mm±1mm2000mm±5mm< 2%
2mm±0.06600mm±1mm2000mm±5mm< 2%
3mm±0.2500±1mm500±2mm< 2%
4mm±0.2500±1mm500±2mm< 2%



Our testing for molybdenum block
FeNiCAlON
0.0040.0020.00280.00050.0050.002
SiCaMgCdSbSn
0.0013< 0.001< 0.0005< 0.001< 0.0005< 0.0005
PCuPbBiMo
< 0.001< 0.0005< 0.0005< 0.0005>99.95%


Molybdenum products

Molybdenum plate/sheet/foil (min 0.05mm); MoLa molybdenum tray

molybdenum rod/bar/wire; molybdenum alloy MoLa box

Molybdenum crucible,molybdenum boat/container,molybdenum tube.

Molybdenum heating element for vacuum furnace and high temperature furnace.

Molybdenum part made to required drawings.

Molybdenum alloy TZM alloy,MoLa alloy. molybdenum block
Tungsten products

Tungsten plate/sheet/foil (min 0.05mm);  molybdenum alloy MoLa boMoLa tray

Tungsten rod/bar/wire; molybdenum block

Tungsten crucible,tungsten boat/container,tungsten tube.

Tungsten heating element for vacuum furnace and high temperature furnace.

Tungsten part made to customer's drawings.

Tungsten alloyWCu alloy,WLa,WNiFe and WNiCu heavy alloy. molybdenum block
Company Profile
High polished tungsten carbide ball mill grinding jar for planetary ball mills carbide grinding bowl(图2)
Zhuzhou Zhenfang Tungsten Molybdenum Co., Ltd. located in Zhuzhou City, Hunan Province-the world-renowned research and production base of nonferrous metal. Our company has over 10 years' experience in manufacture ,design and sale of  carbide products. We have ourown two factories- Zhuzhou Mincheng and Zhuzhou Teliya. Our perfect quality control systerm guarantees our products quality.  Our main products include: tungsten carbide rods, carbide sheet, carbide wear parts,  carbide cutting tools, carbide moulds,non-standard and deep processing products,etc; pure tugnsten rod,tugnsten wire, molybdenum wire. We also accept all kinds of special designed carbide products. Our company gathered professional staffs in design, producing and sale. We treat "High quality","Best price",Sincere service" as the soul of our factory. We try our best to supply more reliable and economical products to our clients. We always seek Win-Win cooperation with our clients. Warmly welcome to contact and visit us at any time. It is our pleasure to help you.
FAQ
1. who are we?
We are based in Hunan, China, start from 2011,sell to Southeast Asia(18.00%),North America(11.00%),South America(10.00%),Western Europe(9.20%),Eastern Asia(8.00%),Eastern Europe(7.00%),Northern Europe(5.00%),South Asia(5.00%),Southern Europe(3.00%),Mid East(2.00%),Central America(1.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
tungsten carbide rod,tungsten carbide bar,tungsten carbide wear parts,tungsten carbide blanks,tungsten carbide cutting tools tips

4. why should you buy from us not from other suppliers?
We have over 10 years experience in tugnsten carbide manufacturing  and developing.  Perfect quality control systerm. High products quality and speedy delivery.  professional sales team. Customization is accepted.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,Express Delivery;
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
