Cemented Carbide Rods

  • K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory
  • K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory
  • K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory
  • K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory
  • K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory
K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory

K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory

  • Place of Origin: China
  • Brand Name: Zhenfang
  • Certification: ISO9001:2015
  • Grade: YG6, yg8, YG10.2L, YG15 etc
  • Minimum Order Quantity:100 pcs
  • Price:USD 45-58/kg
  • Delivery Time:3-5 days
  • Payment Terms:30% after confirming order the balance before shiping
  • Supply Ability:100000 pcs/month

K20 Tungsten Blanks Rod Cemented Carbide Drilling Rod Factory


Size: diameter from 1 to 22mm, length 330mm in stock, Tungsten carbide rod(can customize)
Grade: YL10.2
Material: Tungsten Carbide
Application: wearing parts
Hardness: HRA91
Strength: > 690Mpa
Advantage: high ware-resistance.
Applications of Solid Tungsten Carbide Rods
solid tungsten carbide rods are used for cutting aluminum alloy, cast iron, stainless steel, refractory alloy steel, nickel-based alloy, titanium alloy, and nonferrous metals. Various carbide grades with stable properties have been widely recognized by worldwide makers of tools. Besides, solid tungsten carbide rods are widely used processed as HSS Cutting tool, carbide end mills, carbide cutting tool, NAS cutting tool, carbide end mill, aerospace cutting tool, carbide drill, high speed steel, milling cutter
Core drill, tapered end mills, metric end mills, miniature end mills, pilot reamer, electronics cutter, step drill, metal cutting saw, double margin drill, gun barrel, angle milling cutter, carbide burrs, carbide tipped cutter.

Advantge of Our tungsten carbide rod
1. We are factory ,guarantee competitive price and high quality.
2. High density,Good machinability ,High modulus of elasticity ,Strong corrosion resistance,Good mechanical properties
3. It can effectively absorb X rays and gamma rays (the absorption of X rays andγ rays is higher than lead 30~40%)
4. 100% QC inspection Before Shipment.
5. We guarantee that all of our products are used with 100% Virgin Raw Material.
6. Customization is avaliable

Detail Production Information:

Key Features:

1.High melting point (3410°C)
2. low thermal expansion
3.High resistance
4. Vapor pressure is low
5. Good thermal conductivity
6. High density

Application:
1.Suitable for the production of ion implantation parts
2.production of electric light source parts and electric vacuum parts and elements and refractory parts
3.used as heating elements and refractory parts in high temperature furnaces
4.Used as electrode for rare earth metal industry
5.Electrode in the field of equipment and processing technology or in the lighting industry.
Recommanded grades for your reference
Grade
ISO Range
Cobalt%
Density
g/cm3
Hardness
HRA
YG8
K30
8
14.8
89.5
YG6
K30
6
14.95
90.5
YG6X
K10
6
14.95
91.5
YL10.2
K30
10
14.5
91.8
YG15
K40
15
14
87.5
Dimension
Tolerance of diameter(mm)
Tolerance of length(mm)
ZF-Φ1-3*330
0/+0.3
+0/+5
ZF-Φ4*330
+0.3/+0.5
ZF-Φ6*330
ZF-Φ8*330
ZF-Φ10*330
ZF-Φ12*330
+0.3/+0.7
ZF-Φ14*330
ZF-Φ16*330
ZF-Φ18*330
+0.5/+1.0
ZF-Φ20*330
ZF-Φ22*330
ZF-Φ24*330
ZF-Φ26*330
ZF-Φ28*330
ZF-Φ30*330
ZF-Φ32*330
+0.7/+1.5
ZF-Φ33*330
We are able to help you customized various diameter and length carbide rod. gound or unground both available. We generally have inventory size from Dia1mm to Dia20mm with Length 300mm/330mm
Our advantage of tungsten carbide rod
* ISO 9001:2015 Certification
* Use 100% tungsten carbide raw material
* Advanced technology , automatic pressing , HIP sintering
* with over ten year experience
* And precision grinding
* the tolerance of polish and ground can be +0.005/-0.005mm
* Full ability to accept OEM & ODM orders
* Stringent quality control and quality consistency.
* Strict inspection for quality of raw material and finished products
We Guarantee:
1. produced with advanced equipments and process.
2. high quality durable tungsten carbide rod blanks/cemented rods for milling for router bits made from 100% virgin raw material.
3. all products go through in-process and final inspection.
4. Quality Control System and strict inspection.
5. stable and continuous production ability.
6. free online technical service available.
7. OEM and ODM are accepted as well.
8. Our solid carbide rods are known for constantly providing maximum quality. You can rely on our products as a basis for
consistent performance capacity of your tools.
9. Undertake orders of non-standard sizes at customer's requests.
We can offer a lot of type tungsten carbide rods:
1. un-gound, finish-ground in metric and imperial diameters;
2. Carbide rods with central coolant duct;
3. Fixed length Carbide Rod
4. Random Length carbide rod
5. Carbide rods with chamfered end.

For more size information, please kindly email or call us.For length, we can cut to any size.

Our packing

Based on Detail products, we use different Standard packing suitable overseas shipment.

For  carbide rod packing as following

1. outsizde carton or plywood case

2. inner packing is plastic box or small carton with cotton or paper protection
