Dia3.175mm Tungsten Carbide Drill Blanks / Carbide Round Bar For Mico Drill

  • Place of Origin: Zhuzhou, Hunan
  • Brand Name: Zhenfang
  • Certification: ISO9001:2015
  • Grade: ZF-R238
  • Minimum Order Quantity:10 pcs
  • Price:negotiable
  • Delivery Time:3-10days
  • Payment Terms:L/C, D/A, D/P, T/T, Western Union
  • Supply Ability:15tons/month

For more information, warmly welcome to contact me

Shirley Pan

Email:shirley@chinahardalloy.com

Mobile:+8617773379950


Dia3.175mm Tungsten Carbide Drill Blanks / Carbide Round Rod For Mico Drill

Product information:

1. Grade: YL10.2, YG12X or tohers

2. Size: Diameter 0.5~32mm, cut to any length.

3. Finish: Ground to h5 / h6 tolerance

Features of tungsten carbide rods:

1.100% virgin raw materials with ultrafine partical size

2. HIP sintered, the structure of tungsten carbide is more uniform, more dense, the TRS can be raised more than 20%

3. High precision, high stability and excellent performance, can meet high quality requirement.

4. Excellent abrasive wear resistance leads to long tool life.

5. Competitive price and Fast delivery

Application:

Widely used for making various kinds of carbide solid tools, such as reamers, twist drills, end mills, thread taps, etc. Suitable for machining cast irons, stainless steel, nickel based alloys,titanium alloys, etc.

Physical Properties:

GradeDensity g/cm3Hardness HRA(hv)T.R.S (M Pa)Performances &applications recommended
YL10.214.592.53800Wear resistance and strength comparatively higher,suitable for processing cast iron, non-ferrous metal and non-metalloid materials.
YG614.989.52150Good Wear resistance, used for hard wood,processing original wood,aluminum section bar,brass rod and cast iron.
YG6X14.9921900With fine grain size,Good Wear resistance, used for hard wood,processing original wood,aluminum section bar,
YG814.6892320Suitable for the roughening of cast iron and light alloys and also for the milling of cast iron and low-alloy steel.
YG1114.487.52260Medium grain, for wear parts and mining tools
YG12X14.192-92.53800.It is recommended for making conventional tools,such as twist drill,end mills,screw taps,gun drill,ect.
YG1514.186.52400Medium grain, for mining tools, cold heading and punching dies
YS2T14.4592.52800Fine carbide,high wear resistance,high bending strength,high resistance to bonding, high thermal strength.Machining of refractory alloys, stainless steel and high manganese steel etc.Mainly used for disc cutter and other tools
YNi814.688.51710This grade with 8% nickel binder, it has good wear resistance& corrosion resistance performance ,especially used for high pressure environmental , also good for cutting the titanium alloy.

Other grade is also available. we also can customize composition for you.

Tungsten Carbide Rod Features

- Manufactured with good quality tungsten carbide material

Dimension: Dia10/12/14*100/150/200/330mm   any length can be cut

Tolerance:  Ground h6/h7..., blank(+0.3/0.5mm) based on requirement

Type:           Solid round bar

Performance:  good wear resistance and toughness, corrosion resistance, high temperature resistance,stable chemical properties.

Main application: is for making PCB drills, drills,endmills and reamers, wear parts, and stamping dies, measuring tools.
- Anti-deformation and deflection.
- Produces tungsten carbide rods with extrusion equipment and HIP sintering furnace

- 100% inspection before shipment which garantee good quality

Customized: accepted

Our common size models:

Size range(DiaXL mm)
Tolerance
D(blank, mm)
D (ground, mm)
L(mm)
Dia(0.4-5)x330
+0.3/+0.4
h6/h7
0/+2
Dia(6-20)x330
+0.3/+0.6
h6/h7
0/+2
Dia(21-40)x330
+0.5/1.0
h6/h7
0/+3
                We are able to help you customized various diameter and length carbide rod

Our Packing of tungsten carbide rod

1. outside packing: carton or plywood case
2. inner packing: Bubble wrap and small box
Dia3.175mm Tungsten Carbide Drill Blanks / Carbide Round Bar For Mico Drill(图1)

Product Show

Dia3.175mm Tungsten Carbide Drill Blanks / Carbide Round Bar For Mico Drill(图2)

Dia3.175mm Tungsten Carbide Drill Blanks / Carbide Round Bar For Mico Drill(图3)
