Molybdenum Products

  • Customize high purity molybdenum product for electrode  nonstandard molybdenum strip
  • Customize high purity molybdenum product for electrode  nonstandard molybdenum strip
  • Customize high purity molybdenum product for electrode  nonstandard molybdenum strip
Customize high purity molybdenum product for electrode  nonstandard molybdenum strip Customize high purity molybdenum product for electrode  nonstandard molybdenum strip Customize high purity molybdenum product for electrode  nonstandard molybdenum strip

Customize high purity molybdenum product for electrode nonstandard molybdenum strip

  • Place of Origin: China
  • Brand Name: Zhenfang
  • Certification: ISO9001:2015
  • Grade: Mo 1
  • Minimum Order Quantity:10 pcs
  • Price:USD 8-10
  • Delivery Time:15-25 days
  • Payment Terms:T/T, western union,
  • Supply Ability:1000000 pcs/month

Customize high purity molybdenum product for electrode  nonstandard molybdenum strip


Customize high purity molybdenum product for electrode  nonstandard molybdenum strip

Molybdenum are used to make electrodes, high temperature forming rods, support wires, lead-in wires, printer pins, various electrodes, heating elements of quartz furnace, etc


Feature
1.High resistance to radiation;
2.High ultimate tensile strength;
3.High temperature resistance;
4. Deep processing property significantly increased;
5. Weldability and oxidation resistance greatly enhanced;
6.Yield increase and cost reduction.

Application
* The war industry with the ball core,the ball link.the shrapnel,the armor-piercing shell uses the ball

* Substitutional material for Uranium

* Electroheat upsetting anvil block

* High voltage electrical contact

* Electrodes for Resistance Welding

Advantage

Molybdenum plate has so many advantages, such as high density, high melting point, small volume, excellent hardness, superior wearing resistance, high ultimate tensile strength, high ductility, high temperature resistance, etc. Molybdenum alloys are widely used in many industrial sectors.
Molybdenum alloy plate can be easily used for car weighting .The product also is manufactured as the parts of military defense, extrusion die, various counterweights, such as yacht counterweights, vehicle counterweights, airplane counterweights, helicopter counterweights, boat counterweights, tank counterweights, etc.Usually, molybdenum  alloy cylinder could be manufactured as the parts for military applications, extrusion die and various kinds of counterweights.


Specification:

Purity:>=99.95%

Density:>=10.2g/cm3

Thickness :>=0.1mm

Width: 20-600mm
Length: Less than 2000mm

Standard:ASTM,GB3876-83



Molybdenum block
Thickness(mm)tolerances(mm)width(mm)tolerances(mm)length(mm)tolerances(mm)flatness(%)
0.1mm±0.01600mm±1mm2000mm±5mm< 2%
0.2mm±0.02600mm±1mm2000mm±5mm< 2%
0.3mm±0.02600mm±1mm2000mm±5mm< 2%
0.4mm±0.03600mm±1mm2000mm±5mm< 2%
0.5mm±0.03600mm±1mm2000mm±5mm< 2%
0.8mm±0.05600mm±1mm2000mm±5mm< 2%
1mm±0.06600mm±1mm2000mm±5mm< 2%
1.5mm±0.06600mm±1mm2000mm±5mm< 2%
2mm±0.06600mm±1mm2000mm±5mm< 2%
3mm±0.2500±1mm500±2mm< 2%
4mm±0.2500±1mm500±2mm< 2%



Our testing for molybdenum block
FeNiCAlON
0.0040.0020.00280.00050.0050.002
SiCaMgCdSbSn
0.0013< 0.001< 0.0005< 0.001< 0.0005< 0.0005
PCuPbBiMo
< 0.001< 0.0005< 0.0005< 0.0005>99.95%


Molybdenum products

Molybdenum plate/sheet/foil (min 0.05mm); MoLa molybdenum tray

molybdenum rod/bar/wire; molybdenum alloy MoLa box

Molybdenum crucible,molybdenum boat/container,molybdenum tube.

Molybdenum heating element for vacuum furnace and high temperature furnace.

Molybdenum part made to required drawings.

Molybdenum alloy TZM alloy,MoLa alloy. molybdenum block
Tungsten products

Tungsten plate/sheet/foil (min 0.05mm);  molybdenum alloy MoLa boMoLa tray

Tungsten rod/bar/wire; molybdenum block

Tungsten crucible,tungsten boat/container,tungsten tube.

Tungsten heating element for vacuum furnace and high temperature furnace.

Tungsten part made to customer's drawings.

Tungsten alloyWCu alloy,WLa,WNiFe and WNiCu heavy alloy. molybdenum block
