Ground Tungsten Carbide Rod

  • H6 ground durable tungsten carbide rod
  • H6 ground durable tungsten carbide rod
  • H6 ground durable tungsten carbide rod
  • H6 ground durable tungsten carbide rod
H6 ground durable tungsten carbide rod H6 ground durable tungsten carbide rod H6 ground durable tungsten carbide rod H6 ground durable tungsten carbide rod

H6 ground durable tungsten carbide rod

  • Place of Origin: China
  • Brand Name: Zhenfang
  • Certification: ISO9001:2015
  • Grade: ZF0057
  • Minimum Order Quantity:10 pcs
  • Price:USD 45-58/kg
  • Delivery Time:3-5 days
  • Payment Terms:100% TT before shiping
  • Supply Ability:100000 pcs/month

H6 ground durable tungsten carbide rod


 Specifications

A. Overpressure sintering tungsten carbide rod have excellent red toughness,high hardness,good wear resistance,high elasticmodulus,high strength,good chemical stability,acid,alkali,high temperatureoxidation),Low impact toughness,low
expansion coefficient,thermal conductivity,the characteristics of the conductive similar to iron and other alloy.

1.   having all kind sizes for your choose,can suply less than 1000mm length.

2.   Sintere by vacuum sintering furnace and HIP machine with excellent specifications without any hole.

3.   suply blank plate with tolerance(-0.15~+0.15)or (0~+0.3).

4.   can grinding and polishing the diameter, making chamfer,sharper rod end.

5.   process the carbide rod according your request and tolerances.


Types of Solid Carbide Rods.

a. Carbide rod with chamfer on one end
b. Carbide rods pressed and extruded
c. Carbide rods with a single straight hole


GRADE
ISO
DENSITY
(g/cm³)
TRS
(N/mm²)
HARDNESS
(HRA)
APPLICATION
TF12
K40
14.05
3200
91.8
It is recommended for manufacturing of all types of drills, end mills, reaming, carving tools, suitable for dealing with stainless steel,nichrome, titanium alloy, heat-treated steel, cast iron, aluminum alloy,fine aluminum, iron, plastic, graphite;
YG15
K40
14
2500
86.5
Excellent impact and shock resistance,

suitable for cemented carbide die blanks

mold core, etc;
YG6X
K10
14.9
1750
91.5
Its wear Resistance is higher than YG6, used for processing hard wood, original  wood, aluminum section bars, brass rod  and cast iron;
YG10X
K30
14.5
2400
91
It is recommended for manufacturing of all  types of drills, end mills, burrs, etc, suitable  for the hole machining of steels,gray cast iron, austenitic stainless steel and  heat-resistance alloy.
YG8
K20
14.7
1900
89
Good wear Resistance, excellent anti-impact  and anti-knocking properties, suitable for the manufacturing of wood working blade and machining ferrous and non-ferrous metal.


Dimension and Tolerance:

Dimension(mm)Tolerance of diameter(mm)Tolerance of length(mm)
Min  BL-Φ3.0×330+0.20/+0.5-0/+5.0
Max  BL-Φ50.0×330+0.30/+0.8-0/+5.0


K10 Hard Metal Rod Tungsten Carbide Rods For Endmill.

1)Extrusion Rods,100% virgin materials

2) We ourselves produce the material from Mineral Tungsten

3) Drying Oven are importing from German

4) Top manufacture of carbide products in China


Cheap price tungsten carbide solid round rod Features?

1. Excellent quality and competitive price

2. 100% raw material and recyle material as per your option

3. Good abrasion, heat and corrosion resistance

4. Various size and shape, grade

What's the  Application?

1.Metal working, process into press tool, blade, cutter, wear parts, Blanks and polishing tungsten carbide plates for machinery lathe to machine HSS material,Alu ,steel,and stainless steel,etc.

2.Wood working,blanks and polishing solid tungsten carbide rods for wood working stone pit industry and mining industry.

3.Stone working,blank and polishing solid tungsten carbide rods for crusher machining of marble,granite,cobblestone,mountain stone,etc.

4.Other application,such as wear resistance parts of punching mold,measuring and cutting industry.

Our Guarantee
1.  Competitive price , but good performance.
2.  Press by CIP and Sintered in HIP furnace
3.  Feedback within 24 hours. More details, please contact us skype/whatsapp: +86-13307338220
4.  ISO9001: 2008 certificate professional manufacturer over 20 years
5.  Fully adopted in advance technology and equipment.
6.  Quality Control System and strict inspection.

7.  OEM and ODM are accepted as well.


Our more products

1. Tungsten Carbide rod
2. Tungsten Carbide Sealed Ring
3. Tugnsten Carbide Wear parts
4. Tugnsten Carbide Dies
5. Tungsten Carbide Non-standard parts

6. Tungsten Carbide Circular Blade


Our Packing and shipment:
PackingOutside Carton or plywood case with inner plastic box.
ShippingUPS,TNT,EMS,Fedex,DHL,or by sea,as you reques

Our factory


Zhuzhou Zhenfang Yaguang Tungsten-Molybdenum Co.,LTD is a professional manufacture in tungsten carbide field. We have engaged in this field for over ten years. We have rich experience on tungsten carbide studying and manufacture.We pursuit providing efficient solution and high quality products for clients. We specialize in tungsten carbide rod, carbide plate&strips, carbide dies, carbide roller, carbide wear parts for petrochemical industry, carbide cutting tools.Tungsten carbide rod and customized wear parts is our advantage.
We always keep good relationship with our clients, enhancing communication


H6 ground durable tungsten carbide rod(图2)


H6 ground durable tungsten carbide rod(图3)



Transport

H6 ground durable tungsten carbide rod(图4)



Contact information

Zhuzhou Zhenfang Yaguang Tungsten-Molybdenum Co., Ltd.
Address: Block 7, ZoneC, Auto Parts Industrial Park, Tianyuan district, Zhuzhou, Hunan, China

Web:www.tungstencarbide-rods.com
Tel: 0086-731-28215800
Fax: 0086-731-28215800
Mobile: 0086-13823202651(wechat/whatsapp)

Email address:sharon@chinahardalloy.com
