Cemented Carbide Rods

  • Blank/ground tungsten carbide rod with one straight coolant hole Dia3x0.6x330mm
  • Blank/ground tungsten carbide rod with one straight coolant hole Dia3x0.6x330mm
  • Blank/ground tungsten carbide rod with one straight coolant hole Dia3x0.6x330mm
Blank/ground tungsten carbide rod with one straight coolant hole Dia3x0.6x330mm Blank/ground tungsten carbide rod with one straight coolant hole Dia3x0.6x330mm Blank/ground tungsten carbide rod with one straight coolant hole Dia3x0.6x330mm

Blank/ground tungsten carbide rod with one straight coolant hole Dia3x0.6x330mm

  • Place of Origin: China
  • Brand Name: Zhenfang
  • Certification: ISO9001:2015
  • Grade: YG10X, YL10.2, YG12X, YG15X etc
  • Minimum Order Quantity:100 pcs
  • Price:USD 55-65/kg
  • Delivery Time:3-5 days
  • Payment Terms:30% after confirming order the balance before shiping
  • Supply Ability:100000 kg/month

Blank/ground tungsten carbide rod with one straight coolant hole Dia3x0.6x330mm


Application of  Carbide rods and bars

Tungsten carbide rod with coolant hole has a wide range of application, such as producing finished cutting tools, such as twist drills, mills, reamers, taps and burrs etc., besides these, they are also widely applied to produce processing tools of making printed circuit boards (PCB), such as micro-drills, big-head drills and gravers etc.

Service
We supply various material grades includes standard YG8, YG6, YG6X, etc. Using good carbide is like using thin kerf saw blades.
The differences are not dramatic but they are important. Good carbide will reduce breakage and give better quality cuts overall.
There are several types of Carbide, including advanced grades. Our R&D Team can supply you with more information about these advanced grades and tungsten carbide grades when you make the inquiry.

Detail Production Information:



Blank/ground tungsten carbide rod with one straight coolant hole Dia3x0.6x330mm(图1)



Cemented carbide rods blanks with one central coolant hole



















TypeD(mm)Toleranced(mm)ToleranceDeviation of holes position≤(mm)L(mm)Tolerance
BΦ4.0×Φ1.0×3304.0+0.2/+0.61.0±0.150.23300/+5
BΦ5.0×Φ1.0×3305.0+0.2/+0.61.0±0.150.23300/+5
BΦ5.0×Φ1.5×3305.0+0.2/+0.61.5±0.150.23300/+5
BΦ6.0×Φ1.0×3306.0+0.2/+0.61.0±0.150.23300/+5
BΦ6.0×Φ1.5×3306.0+0.2/+0.61.5±0.150.23300/+5
BΦ8.0×Φ1.0×3308.0+0.2/+0.61.0±0.150.253300/+5
BΦ8.0×Φ1.5×3308.0+0.2/+0.61.5±0.150.253300/+5
BΦ9.0×Φ1.0×3309.0+0.3/+0.71.0±0.150.253300/+5
BΦ10.0×Φ1.0×33010.0+0.3/+0.71.0±0.150.253300/+5
BΦ10.0×Φ2.0×33010.0+0.3/+0.72.0±0.20.253300/+5
BΦ11.0×Φ1.0×33011.0+0.3/+0.71.0±0.150.253300/+5
BΦ12.0×Φ1.0×33012.0+0.3/+0.71.0±0.150.253300/+5
BΦ12.0×Φ2.0×33012.0+0.3/+0.72.0±0.20.253300/+5
BΦ14.0×Φ2.0×33014.0+0.3/+0.72.0±0.20.253300/+5
BΦ16.0×Φ2.0×33016.0+0.4/+0.82.0±0.20.253300/+5
BΦ16.0×Φ3.0×33016.0+0.4/+0.83.0±0.250.253300/+5
BΦ18.0×Φ3.0×33018.0+0.4/+0.83.0±0.250.33300/+5
BΦ20.0×Φ3.0×33020.0+0.4/+0.83.0±0.250.33300/+5








20.0≤Dia ≤40.0 are available on request





Key Features:

1.High melting point (3410°C)
2. low thermal expansion
3.High resistance
4. Vapor pressure is low
5. Good thermal conductivity
6. High density

Zhuzhou Zhenfang Yaguang Tungsten-Molybdenum Co.,LTD is a professional manufacture in tungsten carbide field. We have engaged in this field for over ten years. We have rich experience on tungsten carbide studying and manufacture. We pursuit providing efficient solution and high quality products for clients. We specialize in tungsten carbide rod, carbide plate&strips, carbide dies, carbide roller, carbide wear parts for petrochemical industry, carbide cutting tools.Tungsten carbide rod and customized wear parts is our advantage.

We always keep good relationship with our clients, enhancing communication and cooperation to each other, trying to create WIN-WIN cooperation.


Our Service

1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.

FAQ

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Q4. How about your delivery time?
A: Generally, it will take 10 to 15 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
the courier cost.

Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.


If have any more question, please feel free to contact with us.
