High density alloy tungsten weights pinewood derby car weight tungsten cylinder
- Place of Origin： China
- Brand Name： Zhenfang
- Certification： ISO9001:2015
- Grade： W1
- Minimum Order Quantity:10 pcs
- Price:USD 45-58/kg
- Delivery Time:7-15 days
- Payment Terms:30% after confirming order the balance before shiping
- Supply Ability:
High density alloy tungsten weights pinewood derby car weight tungsten cylinder
Product Description:
Grade:W1 99.95%,95WNiFe alloy
Material:Pure Tungsten or WNiFe alloy
Shape:cylinder,cube,column,block.
Density:19.3g/cm3,18.0-18.5g/cm3
Cylinder Dimensions:3/8''( 9.525mm)
Unit weight:0.5 oz,0.125 oz,0.25 oz, 0.2 oz etc or as per your request.
Cube:1/4''(6.35*6.35*6.35mm),10*10*10mm,24*24*24mm 1kg cube,2 kg cube or as per request.
Material Physical and mechanical properties:
| Alloy Type | 90 W | 92.5 W | 93W | 95 W | 97 W |
| (%)> | 7 Ni | 5.25 Ni | 5Ni | 3.5 Ni | 2.1 Ni |
| 3 Fe | 2.25 Fe | 2Fe | 1.5 Fe | 0.9 Fe | |
| MIL-T-21014 | Class 1 | Class 1 | -- | Class 3 | Class 4 |
| SAE-AMS-T-21014 | Class 1 | Class 2 | -- | Class 3 | Class 4 |
| ASTM B777-87 | Class 1 | Class 2 | -- | Class 3 | Class 4 |
| Typical Density | 17.1 | 17.5 | 17.6 | 18 | 18.5 |
| Typical Hardness RC | 25 | 26 | 26 | 27 | 28 |
| Yield Strength Min | 650~850 | 650~850 | 650~850 | 600~750 | 620~670 |
| (Mpa) | |||||
| Elongation % | 20~25 | 18~24 | 15~20 | 8~13 | 2~5 |
| Magnetic | Slightly | Slightly | Slightly | Slightly | Slightly |
1. produced with advanced equipments and process.
2. high quality durable tungsten carbide rod blanks/cemented rods for milling for router bits made from 100% virgin raw material.
3. all products go through in-process and final inspection.
4. Quality Control System and strict inspection.
5. stable and continuous production ability.
6. free online technical service available.
7. OEM and ODM are accepted as well.
8. Our solid carbide rods are known for constantly providing maximum quality. You can rely on our products as a basis for
consistent performance capacity of your tools.
9. Undertake orders of non-standard sizes at customer's requests.
We can offer a lot of type tungsten carbide rods:
1. un-gound, finish-ground in metric and imperial diameters;2. Carbide rods with central coolant duct;
3. Fixed length Carbide Rod
4. Random Length carbide rod
5. Carbide rods with chamfered end.
1. Tungsten Carbide rod
2. Tungsten Carbide Sealed Ring
3. Tugnsten Carbide Wear parts
4. Tugnsten Carbide Dies
5. Tungsten Carbide Non-standard parts
6. Tungsten Carbide Circular Blade
If have any more information, please feel free to contact with me.
Email:sharon@chinahardalloy.com
Mobile phone:+86-18173388506
Website:www.wmcarbide.com
