Tungsten Carbide Round Bar

Corrosion Resistant Cemented Carbide Rods YL10.2 YG10X YG6X For Making Burrs

Corrosion Resistant Cemented Carbide Rods YL10.2 YG10X YG6X For Making Burrs

Place of Origin： Zhuzhou, Hunan
Brand Name： Zhenfang
Certification： ISO9001:2015
Grade： ZF-187
Minimum Order Quantity:10 pcs
Price:negotiable
Delivery Time:3-10days
Payment Terms:L/C, D/A, D/P, T/T, Western Union
Supply Ability:15tons/month

For more information, warmly welcomr to contact me

Shirley Pan

Email:shirley@chinahardalloy.com

Mobile:+8617773379950

Corrosion Resistant Cemented Carbide Rods YL10.2 YG10X YG6X For Making Burrs

Our Solid carbide rod has good straightness, excellent hardness, and stable toughness.With high wear / corrosion resistance, suitable for the manufacturing of various kind of solid cemented carbide tools for the machining of heat-resistant alloy and Ti alloy,also suitable for the manufacturing of micro drills used for machining PCB.

We offer:

pressed and extruded unground, ground and polished rods with or without chamfers
rod products that can be ground to h6 tolerances
carbide rod with one or two parallel holes
a variety of grades that provide exceptional wear and impact resistance
grades for use in end mills, reamers, drills, countersinks, engraving tools, routers, and other rotary tools
grades for use in a broad range of applications in almost any material
grade for stamping /colding/ forging dies

We make tungsten carbide rods extruded or pressed.

Diameter from 0.3mm to 40mm,

length in 310mm, 330mm or 340mm.

Grade inYL10.2, K10, K20 K30, K35 or etc.

Production Features

All carbide rods are made from the best tungsten carbide powders. The carbide rods are with submicron and average grain size ,the powder is even and stick together firmly,the purity of tungsten carbide powders is quite high.
All carbide rods are made by the extrusion machine which insure that the inside structure of carbide rods is excellent and apprerance of carbide rods if better ,the flatness is improved a lot .
All carbide rods are through HIP sintering which insure that the inside structure of carbide rods is free pore and can stick together firmly .Also the TRS is improved around 30% after HIP sintering
large stock of regular sizes of carbide rods ,which can enable us to make the delivery within 24 hours.
Replacement .we will replace the carbide rods for you if there is any defects.

Specification

Material:	tungsten carbide
Dimension:	Dia1075/100/150mm 2.0330mm various size for choose
Ground Tolerance:	h6 based on requirement
Blank tolerancce:	+0.3~0.5mm
Grade:	K20 K30 K10, YL10.2, YG20 YG10X
Production Process:	Power mixing-Pressing-HIP sintering-Blank- Processing- Finished
Type:	round rod
Surface:	blank or grinding
Performance	High hardness, wear /corrosion resistancce, good toughness, good straightness
Non-standard or tolerance	can be customized

Our standard size models:

Size range(DiaXL mm)	Tolerance
Size range(DiaXL mm)	D(blank, mm)	D (ground, mm)	L(mm)
Dia(0.3-0.9)x330	+0/+0.3	h6/h7	0/+2
Dia(1-5)x330	+0.3/+0.4	h6/h7	0/+2
Dia(6-20)x330	+0.3/+0.6	h6/h7	0/+2
Dia(21-40)x330	+0.5/1.0	h6/h7	0/+3
For any other sizes, we are able to custom-made according to clients’ requirements or drawings.

Carbide Rod Grade Information

Carbide Rods Grades for Cutting Tools

Grade	ISO Grade	WC%	Co%	Grain Size μm	Hardness (HRA)	Density g/cm3	T.R.S. N/mm2	Application
YG6X	K10	94	6	0.6-0.8	14.9	92	2000	Suitable for processing Chilled cast iron, heat-resistant alloy steel, and fine process of common cast iron
YL10.2	K25-K35	90	10	0.6-0.8	14.5	92.5	3800	Wear resistance and strength comparatively higher,suitable for PCB micro drills,for making drills,end mill,reamer,taps,burrs etc.
YG10X	K35	90	10	0.6-0.8	14.5	90	2200	Suitable for Small diameter bit, end milling cutter, rotary file

Cutting steel class grade

Grade	ISO Grade	Density g/cm3	Hardness HRA	T.R.S N/mm2	Application
YT5	P30	11.50-13.20	90.0	1750	Suitable for heavy duty cutting of steel and cast steel and for a low-speed and medium-speed and a big feed-rate roughing operation under unfavorable machining conditions
YT14	P20	11.20-11.80	91.0	1550	Suitable for semi-finishing and finishing machining of steel and cast steel, using a medium feed-rate
YT15	P10	11.10-11.60	91.5	1500	Suitable for semi-finishing and finishing machining of steel and cast steel and a medium feed-rate and a rather high cutting speed is to be recommended
YC40	P40	13.00-13.40	89.5	1860	Suitable for heavy duty cutting of steel and cast steel with a possible big feed-rate and for face milling as well.
YW1	M10	12.85-13.40	92.0	1380	Suitable for semi-finishing and finishing of stainless and ordinary alloyed steel
YW2	M20	12.65-13.35	91.0	1680	Suitable for semi-finishing and finishing of stainless and low alloyed steel, mainly used for machining of trains' wheel hubs
YW3	M10	12.85-13.10	92.0	1420	It is suitable for semi-finishing and finishing of stainless and ordinary alloyed steel
