Plunger

  • High Pressure Pump Tungsten Carbide Plunger Dia15x277
  • High Pressure Pump Tungsten Carbide Plunger Dia15x277
  • High Pressure Pump Tungsten Carbide Plunger Dia15x277
  • High Pressure Pump Tungsten Carbide Plunger Dia15x277
High Pressure Pump Tungsten Carbide Plunger Dia15x277 High Pressure Pump Tungsten Carbide Plunger Dia15x277 High Pressure Pump Tungsten Carbide Plunger Dia15x277 High Pressure Pump Tungsten Carbide Plunger Dia15x277

High Pressure Pump Tungsten Carbide Plunger Dia15x277

  • Place of Origin: Zhuzhou, Hunan
  • Brand Name: Zhenfang
  • Certification: ISO9001:2015
  • Grade: K10 K20 K30 YL10.2 YN8 YN9
  • Minimum Order Quantity:3 pcs
  • Price:Negotiable
  • Delivery Time:3-15days
  • Payment Terms:L/C, D/A, D/P, T/T, Western Union
  • Supply Ability:15tons/month

High Pressure Pump Tungsten Carbide Plunger Dia15x277

For more information, warmly welcome to contact me

Shirley Pan(Ms)

Email:shirley@chinahardalloy.com

Mobile:+8617773379950


High Pressure Pump Tungsten Carbide Plunger Dia15x277

Solid tungsten carbide plungers provide unequaled performance in a critical, demanding, and dangerous environment of 50,000 psi and 750,000,000 cycles before repair. Extremely tight tolerances and finishes along with premium quality materials and experienced knowledge of the service demands, result in smooth operating cylinders and packing life.

Detail Information

1. Material: WC+Ni/WC+Co

2. Grade:YN8 YG11 YG8
3. Hardness: HRA89-90   Bending strength:3500
3. Size: Dia15*277mm   dia33.33*270mm   Customized
4. Features: High Wear Resistance, Corrosion Resistance
5. Surface finishing: Ra0.2-0.4
6. Straightness:0.005
7. Technology: HIP sintering
 All technical data only for reference. We can make based on requirement
Grade Information for plunger
Grade
Density(g/cm3)
Hardness(HRA)
Toughness(N/mm2)
Composition
YG6
14.9
89.5
2150
Co 6%
YG8
14.6
89
2320
Co 8%
YG11
14.3
88
2500
11%Co
YN6
14.8-15
91
2100
Ni 6%
YN8
14.2
90.5
2300
Ni 8%
YN9
14.7
89.5
2200
Ni 9%
YN12
14.3
86.5
2250
Ni 12%

Application Range:

our tungsten carbide plunger widely used in high pressure pump, high pressure cleaning pump, High-power high-pressure pump group, High Pressure Pump Automatic Set,Pipe dredge, High-pressure oil injection machinery etc.

Our advantage:
1. Material: using high quality raw material
2. Production Procedure: Powder preparing- Pressing-HIP sintering- Processing-Finishing
3. Perfect quality control systerm: ISO9001:2015
4. Various dimension for choosing
5. Various grade for choosing based on your application. the hardness is from HRA82 to HRA92.5
6. We also accept manufacturing based on your drawing

With unmatched wear resistant and a high polished finish for extreme pressure pumping of various fluids and gasses, our high pressure plungers will increase your pump’s internal life cycle.
